| MODEL | CD6240C | CD6250C | CD6260C |
| CAPACTIES | Max. swing over bed mm | 400 | 500 | 600 |
| Max. swing over cross slide mm | 225 | 325 | 360 |
| Max. swing in gap mm | 530 | 630 | 730 |
| Center distance | 1000,1500,2000mm |
| Cross slide travel mm | 330mm |
| SPINDLE | Spindle hole | 80mm |
| Spindle nose | ISO-C8 or ISO-D8 |
| Spindle taper | Metric 85mm |
| Spindle speeds | 24-1600rpm (15 Steps) |
| FEEDS | Metric threads range (Kinds) | 0.5-28mm (66Kinds) |
| Inch threads range (Kinds) | 1-56tpi (66 Kinds) |
| Module threads range (Kinds) | 0.5-3.5mm (33 Kinds) |
| Diametral threads range (Kinds) | 8-56 DP (33 Kinds) |
| Longitudinal feeds range(kinds) | 0.072-4.038mm/reV
(0.0027-0.15inch/rev)(66kinds) |
| Cross feeds range (kinds) | 0.036-2.019mm/reV
(0.0013-0.075nch/rev)(66kinds) |
| Rapid traveling speed of carriage | 5m/min(16.4ft/min) |
| Leadscrew size:Diameter pitch | 35mm/6mm or 35mm |
| CARRIAGE | Cross slide travel | 300mm |
| Compound rest travel | 130mm |
| Cross-section size of tool shank | 25x25mm |
