| Spindle feeding steps | 8 |
| Spindle feed range | 25-285mm/min |
| Spindle taper | 7:24 IS040 |
| Manual axial movement of the spindle (mm) | 80 |
| The movement of each grid on the dial(mm) | 0.5 |
| Spindle body rotation angle | -45 |
| Spindle speed level | 8 |
| Spindle speed range | 150-1660r/min |
| Distance from the centerline of the horizontal spindle to the lower plane of the upper beam(mm) | 96 |
| Distance
from the front edge of the horizontal tableand thefront plane of the
vertical guide rail of the bed due todifferent installation
positions(mm) | 212-412 |
| Distance between the centerline of the vertical spindle andthe front plane of the vertical guide rail of the bed(mm) | 155 |
| Distance between the lower end face of the vertical spindleand the plane on the horizontal table(mm) | 0-285 |
| Total power capacity(kVA) | 4 |
| Main motor power(kw) | 3 |
| Main motor speed(r/min) | 1430 |
| Cooling water pump motor(w) | 40 |
| Machine tool dimensions(longxwide xhigh)(mm) | 1450x1445x1650 |
